Ponp labou F-seri triplex nou yo fèt ak fabrike ki baze sou ponp labou seri Ameriken Emsco F-seri an akò ak spesifikasyon API 7K. Tout pati pyès sa yo ka ranplase ak nenpòt lòt pyès rezèv ki sanble pwodwi dapre spesifikasyon API. Se poutèt sa, reparasyon ak antretyen nan pwodwi nou yo posib atravè mond lan.
Karakteristik
-
Ponp labou triplex nou an prezante yon konsepsyon kontra enfòmèl ant ak gaya, ki ofri yon ti anprint san yo pa konpwomèt sou pouvwa. Enjenieri pou pèfòmans segondè, li satisfè egzijans teknik egzijans presyon ponpe segondè ak gwo deplasman nan operasyon perçage modèn.
-
Ponp lan fèt ak yon longè konjesyon serebral pwolonje epi li opere nan yon vitès konjesyon serebral pi ba. Konbinezon sa a siyifikativman amelyore efikasite konsomasyon likid ponp lan epi li pwolonje anpil lavi sèvis likid -pati ki pa gen anpil valè. Enkòporasyon an nan yon dampener pulsasyon avanse pou aspirasyon plis asire pèfòmans pi bon pou aspirasyon anba divès kondisyon opere.
-
Nan fen pouvwa a, se yon sistèm lubrification doub konbine metòd fòse ak Splash. Sa a achitekti lubrification serye efektivman amelyore durability ak pwolonje lavi sa a ki sèvis nan eleman yo fen pouvwa.
Spesifikasyon RLF-300 Triplex labou ponp
|
Atik |
RLF300 |
|
Pouvwa Antre nominal (KW/HP) |
220kW (300Hp) |
|
Pousantaj konjesyon serebral nominal (SPW) |
135 kou/min |
|
Longè kou (mm/pous) |
203mm |
|
Rediksyon Kovèti pou rapò |
4.58 |
|
Dyamèt Inlet aspirasyon |
203mm |
|
Egzeyat Outlet Dyamèt |
80mm |
|
Maksimòm revètman (pous/mm) |
180mm |
|
Valv |
API-5# |
|
Dimansyon jeneral (L × W × H mm) |
3000*1650*1840 |
|
Pwa Ponp (kg) |
6000 |
|
Konjesyon Serebral Ponp |
Dyamèt twou silenn |
180 |
160 |
150 |
140 |
130 |
120 |
110 |
100 |
90 |
|
Presyon ponp nominal (MPa) |
6.6 |
8.3 |
9.5 |
10.8 |
12.7 |
15 |
17.7 |
21.5 |
26.4 |
|
|
Rated pouvwa |
Pousantaj koule (L/s) |
|||||||||
|
135 |
220 |
30 |
23.8 |
20.66 |
18.3 |
15.6 |
13.2 |
11.2 |
9.2 |
7.5 |
|
120 |
195.5 |
26.7 |
21.1 |
18.36 |
16.2 |
13.9 |
11.72 |
9.9 |
8.2 |
6.7 |
|
100 |
163 |
22.3 |
17.6 |
15.3 |
13.5 |
11.6 |
9.8 |
8.3 |
6.8 |
5.6 |
|
Ki baze sou yon efikasite volumetrik nan 100% ak yon efikasite mekanik nan 90%. |
||||||||||
Spesifikasyon RLF-500 Triplex labou ponp
|
Atik |
RLF500 |
|
Pouvwa nominal (hp/kW) |
500 (373) |
|
Pousantaj konjesyon serebral (SPM) |
165 |
|
Longè kou (pous/mm) |
7.5"/190.5 |
|
Rediksyon Kovèti pou rapò |
4.286 |
|
Dyamèt Inlet aspirasyon (pous/mm) |
8"/203 |
|
Dyamèt priz egzeyat (pous) |
4" bride 5000psi |
|
Valv |
API5# |
|
Maksimòm revètman (pous/mm) |
6-3/4"/170 |
|
Dimansyon jeneral (L × W × H mm) |
3658×2709 ×2231 |
|
Apeprè pwa (kg) |
9770 |
|
Konjesyon serebral pou chak minit |
Gwosè revètman (mm) ak presyon nominal (Mpa/psi) |
|||||||
|
φ170 |
φ160 |
φ150 |
φ140 |
φ130 |
φ120 |
φ110 |
φ100 |
|
|
9.41365 |
10.61540 |
12.11750 |
13.92010 |
16.12335 |
18.92740 |
22.53260 |
27.23945 |
|
|
Deplasman (L/S)/(GPM) |
||||||||
|
165 |
35.67565 |
31.60501 |
27.77440 |
24.19383 |
20.86330 |
17.77281 |
14.93236 |
12.34195 |
|
150 |
32.43514 |
28.73455 |
25.25400 |
21.99348 |
18.96300 |
16.16256 |
13.58215 |
11.22178 |
|
140 |
30.27480 |
26.81425 |
23.56373 |
20.53325 |
17.70280 |
15.08239 |
12.67201 |
10.47166 |
|
130 |
28.11445 |
24.90394 |
21.88347 |
19.06302 |
16.44260 |
14.00222 |
11.77186 |
9.73154 |
|
120 |
25.94411 |
22.98364 |
20.20320 |
17.60279 |
15.17240 |
12.93205 |
10.86172 |
8.98142 |
|
110 |
23.78377 |
21.07334 |
18.52293 |
16.13255 |
13.91220 |
11.85188 |
9.96158 |
8.23130 |
|
Ki baze sou 100% efikasite volumetrik ak 90% efikasite mekanik |
||||||||
|
Konjesyon serebral pou chak minit |
Gwosè revètman (pous) ak P rated presyon (Mpa/psi) |
||||||
|
6-3/4 |
6-1/2 |
6 |
5-1/2 |
5 |
4-1/2 |
4 |
|
|
9.251340 |
9.971445 |
11.71695 |
13.932020 |
16.852445 |
20.813020 |
26.333820 |
|
|
Deplasman (L/S)/(GPM) |
|||||||
|
165 |
36.28575 |
33.65533 |
28.67454 |
24.09382 |
19.91316 |
16.13256 |
12.74202 |
|
150 |
32.99523 |
30.59485 |
26.06413 |
21.90347 |
18.10287 |
14.66232 |
11.58184 |
|
140 |
30.79488 |
28.55453 |
24.32385 |
20.44324 |
16.89268 |
13.68217 |
10.81171 |
|
130 |
28.59453 |
26.51420 |
22.59358 |
18.98301 |
15.69249 |
12.71201 |
10.04159 |
|
120 |
26.39418 |
24.47388 |
20.85330 |
17.52278 |
14.48230 |
11.73186 |
9.27147 |
|
110 |
24.19383 |
22.43356 |
19.11303 |
16.06255 |
13.27210 |
10.75170 |
8.49135 |
|
Ki baze sou 100% efikasite volumetrik ak 90% efikasite mekanik |
|||||||
Spesifikasyon RLF-800 Triplex labou ponp
|
Atik |
RLF800 |
|
Pouvwa nominal (hp/kW) |
800 (597) |
|
Pousantaj konjesyon serebral (SPM) |
150 |
|
Longè kou (pous/mm) |
9"/228.6 |
|
Rediksyon Kovèti pou rapò |
4.185 |
|
Dyamèt Inlet aspirasyon (pous/mm) |
10"/254 |
|
Dyamèt priz egzeyat (pous) |
5-1/8" Flange 5000psi |
|
Valv |
API6# |
|
Maksimòm revètman (pous/mm) |
6-3/4"/170 |
|
Dimansyon jeneral (L × W × H mm) |
3963×3025 ×2410 |
|
Apeprè pwa (kg) |
14500 |
|
Konjesyon serebral pou chak minit |
Gwosè revètman (mm) ak presyon nominal (Mpa/psi) |
|||||||
|
φ170 |
φ160 |
φ150 |
φ140 |
φ130 |
φ120 |
φ110 |
φ100 |
|
|
13.82000 |
15.62260 |
17.72570 |
20.32950 |
23.63420 |
27.74015 |
33.04780 |
34.55000 |
|
|
Deplasman (L/S)/(GPM) |
||||||||
|
150 |
38.92617 |
34.47546 |
30.30480 |
26.39418 |
22.76360 |
19.39307 |
16.29258 |
13.47213 |
|
140 |
36.32575 |
32.17510 |
28.28448 |
24.63390 |
21.24336 |
18.10287 |
15.21241 |
12.57199 |
|
130 |
33.73534 |
29.88473 |
26.26416 |
22.87362 |
19.72312 |
16.81266 |
14.12224 |
11.67185 |
|
120 |
31.13493 |
27.58437 |
24.24384 |
21.11334 |
18.21288 |
15.51246 |
13.03206 |
10.77171 |
|
110 |
28.54452 |
25.28400 |
22.22352 |
19.35307 |
16.69264 |
14.22225 |
11.95189 |
9.87156 |
|
Ki baze sou 100% efikasite volumetrik ak 90% efikasite mekanik |
||||||||
|
Konjesyon serebral pou chak minit |
Gwosè revètman (pous) ak presyon nominal (Mpa/psi) |
|||||||
|
6-3/4 |
6-1/2 |
6-1/4 |
6 |
5-1/2 |
5 |
4-1/2 |
4 |
|
|
13.561965 |
14.632120 |
15.822295 |
17.162490 |
20.432965 |
24.723585 |
30.514425 |
355075 |
|
|
Deplasman (L/S)/(GPM) |
||||||||
|
150 |
39.58627 |
36.70582 |
33.94538 |
31.27496 |
26.28417 |
21.72344 |
17.59279 |
13.90220 |
|
140 |
36.94586 |
34.26543 |
31.67502 |
29.19463 |
24.53389 |
20.27321 |
16.42260 |
12.97206 |
|
130 |
34.30544 |
31.81504 |
29.41466 |
27.10430 |
22.78361 |
18.82298 |
15.25242 |
12.05191 |
|
120 |
31.67502 |
29.36465 |
27.15430 |
25.02397 |
21.02333 |
17.37275 |
14.07223 |
11.12176 |
|
110 |
29.03460 |
26.92427 |
24.89395 |
22.93363 |
19.27305 |
15.93252 |
12.90204 |
10.19162 |
|
Ki baze sou 100% efikasite volumetrik ak 90% efikasite mekanik |
||||||||
Spesifikasyon RLF-1000 Triplex labou ponp
|
Atik |
RLF1000 |
|
Pouvwa nominal (hp/kW) |
1000 (746) |
|
Pousantaj konjesyon serebral (SPM) |
140 |
|
Longè kou (pous/mm) |
10"/254 |
|
Rediksyon Kovèti pou rapò |
4.207 |
|
Dyamèt Inlet aspirasyon (pous/mm) |
12"/305 |
|
Dyamèt priz egzeyat (pous) |
5-1/8" Flange 5000psi |
|
Valv |
API6# |
|
Maksimòm revètman (pous/mm) |
6-3/4"/170 |
|
Dimansyon jeneral (L × W × H mm) |
4267×3167 ×2580 |
|
Apeprè pwa (kg) |
18790 |
|
Konjesyon serebral pou chak minit |
Gwosè revètman (mm) ak presyon nominal (Mpa/psi) |
||||||
|
φ170 |
φ160 |
φ150 |
φ140 |
φ130 |
φ120 |
φ110 |
|
|
16.62410 |
18.82725 |
21.43100 |
24.53555 |
28.44125 |
33.44840 |
34.55000 |
|
|
Deplasman (L/S)/(GPM) |
|||||||
|
140 |
40.36639 |
35.75566 |
31.42498 |
27.37434 |
23.60374 |
20.11318 |
16.90268 |
|
130 |
37.47594 |
33.20526 |
29.13462 |
25.42403 |
21.92347 |
18.67296 |
15.69248 |
|
120 |
34.59548 |
30.64485 |
26.93427 |
23.46372 |
20.23320 |
17.24273 |
14.48229 |
|
110 |
31.71502 |
28.09445 |
24.93391 |
21.51341 |
18.54294 |
15.80250 |
13.28210 |
|
100 |
28.83457 |
25.53404 |
22.44355 |
19.55310 |
16.86267 |
14.36227 |
12.07191 |
|
Ki baze sou 100% efikasite volumetrik ak 90% efikasite mekanik |
|||||||
|
Konjesyon serebral pou chak minit |
Gwosè revètman (pous) ak presyon nominal (Mpa/psi) |
|||||||
|
6-3/4 |
6-1/2 |
6-1/4 |
6 |
5-1/2 |
5 |
4-1/2 |
4 |
|
|
16.352370 |
17.632555 |
19.072765 |
20.693000 |
24.623570 |
29.794320 |
355075 |
355075 |
|
|
Deplasman (L/S)/(GPM) |
||||||||
|
140 |
41.05651 |
38.06603 |
35.19558 |
32.43514 |
27.25432 |
22.52357 |
18.24289 |
14.41228 |
|
130 |
38.12604.2 |
35.35560 |
32.68518 |
30.12477 |
25.31401 |
20.91331 |
16.94269 |
13.39212 |
|
120 |
35.18558 |
32.63517 |
30.16478 |
27.80441 |
23.36370 |
19.31306 |
15.64248 |
12.36196 |
|
110 |
32.25511 |
29.91474 |
27.65438 |
25.48404 |
21.41339 |
17.70281 |
14.33227 |
11.33180 |
|
100 |
29.32465 |
27.19431 |
25.14398 |
23.17367 |
19.47309 |
16.09255 |
13.03207 |
10.30163 |
|
Ki baze sou 100% efikasite volumetrik ak 90% efikasite mekanik |
||||||||
Spesifikasyon RLF-1300 Triplex labou ponp
|
Atik |
RLF1300 |
|
Pouvwa nominal (hp/kW) |
1300 (969) |
|
Pousantaj konjesyon serebral (SPM) |
120 |
|
Longè kou (pous/mm) |
12"/305 |
|
Rediksyon Kovèti pou rapò |
4.206 |
|
Dyamèt Inlet aspirasyon (pous/mm) |
12"/305 |
|
Dyamèt priz egzeyat (pous) |
5-1/8" Flange 5000psi |
|
Valv |
API7# |
|
Maksimòm revètman (pous/mm) |
7"/180 |
|
Dimansyon jeneral (L × W × H mm) |
4617×3260 ×2600 |
|
Apeprè pwa (kg) |
24572 |
|
Konjesyon serebral pou chak minit |
Gwosè revètman (mm) ak presyon nominal (Mpa/psi) |
|||||
|
φ180 |
φ170 |
φ160 |
φ150 |
φ140 |
φ130 |
|
|
18.72712 |
213045 |
23.73437 |
273915 |
314495 |
34.55000 |
|
|
Deplasman (L/S)/(GPM) |
||||||
|
120 |
46.54737 |
41.51658 |
36.77583 |
32.32512 |
28.15446 |
24.27385 |
|
110 |
42.66676 |
38.05603 |
33.71534 |
29.62469 |
25.81409 |
22.25352 |
|
100 |
38.78614 |
34.59548 |
30.64485 |
26.93427 |
23.46372 |
20.23320 |
|
90 |
34.9553 |
31.13493 |
27.58437 |
24.24384 |
21.11334 |
18.21288 |
|
Ki baze sou 100% efikasite volumetrik ak 90% efikasite mekanik |
||||||
|
Konjesyon serebral pou chak minit |
Gwosè revètman (pous) ak presyon nominal (Mpa/psi) |
|||||
|
7 |
6-3/4 |
6-1/4 |
6 |
5-1/2 |
5 |
|
|
19.172780 |
20.652994 |
24.073490 |
26.163793 |
31.134539 |
355075 |
|
|
Deplasman (L/S)/(GPM) |
||||||
|
120 |
45.41720 |
42.23669 |
36.20574 |
33.36529 |
28.04444 |
23.17367 |
|
110 |
41.63660 |
38.71614 |
33.19526 |
30.58485 |
25.70407 |
21.24337 |
|
100 |
37.84600 |
35.19558 |
30.17478 |
27.80441 |
23.36370 |
19.31306 |
|
90 |
34.06540 |
31.67502 |
27.15430 |
25.02397 |
21.03333 |
17.38275 |
|
Ki baze sou 100% efikasite volumetrik ak 90% efikasite mekanik |
||||||
Spesifikasyon RLF-1600 Triplex labou ponp
|
Atik |
RLF1600 |
|
Pouvwa nominal (hp/kW) |
1600 (1193) |
|
Pousantaj konjesyon serebral (SPM) |
120 |
|
Longè kou (pous/mm) |
12"/305 |
|
Rediksyon Kovèti pou rapò |
4.206 |
|
Dyamèt Inlet aspirasyon (pous/mm) |
12"/305 |
|
Dyamèt priz egzeyat (pous) |
5-1/8" Flange 5000psi |
|
Valv |
API7# |
|
Maksimòm revètman (pous/mm) |
7"/180 |
|
Dimansyon jeneral (L × W × H mm) |
4615×3276 ×2688 |
|
Apeprè pwa (kg) |
24791 |
|
Konjesyon serebral pou chak minit |
Gwosè revètman (mm) ak presyon nominal (Mpa/psi) |
|||||
|
φ180 |
φ170 |
φ160 |
φ150 |
φ140 |
φ130 |
|
|
23.63345 |
25.93750 |
29.24235 |
33.24820 |
34.55000 |
34.55000 |
|
|
Deplasman (L/S)/(GPM) |
||||||
|
120 |
46.54737 |
41.51658 |
36.77583 |
32.32512 |
28.15446 |
24.27385 |
|
110 |
42.66676 |
38.05603 |
33.71534 |
29.62469 |
25.81409 |
22.25352 |
|
100 |
38.78614 |
34.59548 |
30.64485 |
26.93427 |
23.46372 |
20.23320 |
|
90 |
34.9553 |
31.13493 |
27.58437 |
24.24384 |
21.11334 |
18.21288 |
|
Ki baze sou 100% efikasite volumetrik ak 90% efikasite mekanik |
||||||
|
Konjesyon serebral pou chak minit |
Gwosè revètman (mm) ak presyon nominal (Mpa/psi) |
|||||
|
7 |
6-3/4 |
6-1/4 |
6 |
5-1/2 |
5 |
|
|
24.193508 |
25.463692 |
29.664300 |
32.164663 |
34.55000 |
355075 |
|
|
Deplasman (L/S)/(GPM) |
||||||
|
120 |
45.41720 |
42.23669 |
36.20574 |
33.36529 |
28.04444 |
23.17367 |
|
110 |
41.63660 |
38.71614 |
33.19526 |
30.58485 |
25.70407 |
21.24337 |
|
100 |
37.84600 |
35.19558 |
30.17478 |
27.80441 |
23.36370 |
19.31306 |
|
90 |
34.06540 |
31.67502 |
27.15430 |
25.02397 |
21.03333 |
17.38275 |
|
Ki baze sou 100% efikasite volumetrik ak 90% efikasite mekanik |
||||||
Spesifikasyon RLF-2200 Triplex labou ponp
|
Konjesyon serebral pou chak minit |
Pouvwa nominal (hp) |
Gwosè revètman (mm) ak presyon nominal (Mpa) |
|||||||||
|
φ140 |
φ150 |
φ160 |
φ170 |
φ180 |
φ190 |
φ200 |
φ210 |
φ220 |
φ230 |
||
|
35 |
35 |
35 |
35 |
31 |
27.9 |
25.1 |
22.8 |
20.8 |
19 |
||
|
Deplasman (L/S) |
|||||||||||
|
105 |
2200 |
28.76 |
33.01 |
37.56 |
42.40 |
47.54 |
52.96 |
58.69 |
64.70 |
71.01 |
77.61 |
|
90 |
1886 |
24.65 |
28.30 |
32.19 |
36.34 |
40.75 |
45.40 |
50.30 |
55.46 |
60.87 |
66.53 |
|
80 |
1676 |
21.91 |
25.15 |
28.62 |
32.31 |
36.22 |
40.35 |
44.71 |
49.30 |
54.10 |
59.13 |
|
70 |
1467 |
19.17 |
22.01 |
25.04 |
28.27 |
31.69 |
35.31 |
39.12 |
43.13 |
47.34 |
51.74 |
|
60 |
1257 |
16.43 |
18.86 |
21.46 |
24.23 |
27.16 |
30.27 |
33.54 |
36.97 |
40.58 |
44.35 |
|
1 |
0.2738 |
0.3143 |
0.3577 |
0.4038 |
0.4527 |
0.5045 |
0.5590 |
0.6162 |
0.6763 |
0.7392 |
|
|
Ki baze sou 100% efikasite volumetrik ak 90% efikasite mekanik |
|||||||||||
Baj popilè: f-seri triplex ponp labou, Lachin f-seri triplex ponp labou manifaktirè, founisè, faktori
